GLOBE VALVE

Name: GLOBE VALVE
Brand: ELECTROLOGIC ENGINEERING INDIA PRIVATE LIMITED
Price: 2000 INR
Availability: InStock

Price 2000 INR/ Number

Get a Price/Quote

MOQ : 1 Number

GLOBE VALVE Specification

Mounting Type
Horizontal / Vertical

Connection
Flanged / Screwed / Butt-weld ends

Capacity
Varies as per port size

Noise Level
Low

Flow Rate
Depends on size and design, typically full bore type

Pressure Ratings
PN16, PN25, PN40, Class 150, Class 300

Diameter
DN15 to DN300

Voltage
N/A (Manual Operation)

Valve Type
Globe Valve

IP Rating
N/A (Manual Operation)

Sealing
Metallic / PTFE / Graphite

Application
Industrial, Chemical Plants, Refineries, Petrochemical, Power Plants, Water Supply, HVAC

Standard
ISI / DIN / BS / ANSI

Material
Cast Iron, Cast Steel, Stainless Steel, Brass, Bronze

Temperature
-20°C to 425°C

Media
Water, Oil, Gas, Steam, Air, Chemicals

Structure
Bolted Bonnet, Rising Stem, Disc Type - Plug/Globe

Power
Manual

Port Size
15mm to 300mm

Model
Globe Valve

Pipe Connection Type
Flanged / Threaded / Welded

Packing Type
Braided Graphite / PTFE

Bonnet Type
Bolted Bonnet

Operation
Handwheel Operated

Coating / Finish
Anti-corrosive Black Bitumen / Epoxy Paint

Hydrostatic Test Pressure
1.5 times the working pressure

Direction
Uni-directional / Bi-directional Flow

End Connection Standard
ASME B16.5 / IS:1538 / DIN

Body Cover Joint
Gasketed / Bolted

Stem Material
AISI 410 / AISI 304 / AISI 316

Handwheel Type
Cast Iron / Steel

Disc Design
Plug Type / Disc Type

Face to Face Dimension
As per ANSI B16.10 / DIN 3202

GLOBE VALVE Trade Information

Minimum Order Quantity
1 Number

Supply Ability
10 Per Week

Delivery Time
1 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

GLOBE VALVE About

Size: 1/2"-20" (15NB - 500NB)
Class: 150#-2500#
CS / SS / Alloys / Monel / Hastalloys Steel / Bronze MOC
Parabolic , Regulating, Throttle and Guid Type Plug
Staight "T" Type, "Y" Type, Angle Type.
Speciality : Below Sealed, Cryogenic, High Temp and with pressure balancing arrangement.
Metal to Metal and Metal to soft seat
Manual Operated / Gear Box / Pneumatic / Electrical Actuator

Design : ASME B16.34 / BS 1873
Face to Face : ASME B16.10 / DIN IS
End to End: BW Type / Flanged End / RTJ
Pressure -Temperature Rating : ASTM B 16.34
Screwed End Dimension : ASTM B 1.20.1
BW End: ASME B16.25
Test: API 598 / BS 6755
Fire Safe: NACE MR-01-75 / 0103

Versatile and Reliable Globe Valve Solutions

Our Globe Valve, available in materials such as cast iron, cast steel, stainless steel, brass, or bronze, is engineered to deliver dependable shutoff and throttling for a wide range of media-water, oil, gas, steam, air, and chemicals. Complying with international standards (ISI, DIN, BS, ANSI), this globe valve supports both horizontal and vertical installation and fits various end connections to meet diverse industrial needs.

Superior Construction for Challenging Environments

Each valve features anti-corrosive black bitumen or epoxy paint, robust bolted bonnet structure, and precision-engineered face-to-face dimensions per ANSI B16.10 or DIN 3202. Hydrostatic test pressure at 1.5 times working pressure ensures reliability under demanding conditions. The product adapts to unidirectional or bidirectional flow, delivering performance in refineries, chemical plants, power plants, HVAC, and water supply applications.

FAQ's of GLOBE VALVE:

Q: How is the Globe Valve installed and what end connections are available?

A: Globe Valves can be mounted horizontally or vertically and are available with flanged, threaded (screwed), or butt-weld end connections as per ASME B16.5, IS:1538, or DIN standards. This variety ensures compatibility with diverse pipeline configurations in industrial applications.

Q: What are the benefits of using a plug/disc type Globe Valve with a rising stem design?

A: A plug or disc type Globe Valve fitted with a rising stem offers precise throttling and flow control. The rising stem design allows for visual position indication of the valve (open/closed status), enhancing operational safety and ease of maintenance.

Q: When should I choose PTFE or graphite packing for the valve?

A: PTFE packing is preferred for applications requiring chemical resistance and lower friction, while graphite packing is typically chosen for higher temperature and pressure scenarios, providing robust sealing performance under demanding conditions.

Q: Where can the Globe Valve be used, and for which media is it suitable?

A: These valves are ideal for use in industrial, chemical, petrochemical, power plants, water supply systems, and HVAC installations. They efficiently control the flow of water, oil, gas, steam, air, and chemicals, making them highly versatile in process industries.

Q: What is the process for hydrostatic testing and why is it important for this valve?

A: Each Globe Valve undergoes hydrostatic testing at 1.5 times its working pressure. This process ensures the integrity of the valve's construction and its ability to withstand operational pressures, significantly reducing the risk of leakage or failure during service.

Q: How do the anti-corrosive coatings enhance the valve's performance and longevity?

A: The anti-corrosive black bitumen or epoxy coatings shield the valve surfaces from aggressive media and environmental conditions, substantially increasing lifespan and reducing maintenance needs in corrosive or demanding service environments.
